Underground Coal Mining Conveyor Belt Manufacturers

Brand Name : ZR

Model Number : DT

Place of Origin : Shanghai, China

MOQ : 100m

Price : Price Negotiable

Payment Terms : T/T, T/T, Western Union, MoneyGram

Supply Ability : 1000PCS/Year

Delivery Time : 20-30 days

Packaging Details : Nude Cargo/Pallet/Wooden Case/Customize

Structure : Belt Conveyor

Material : Nylon

Material Feature : Oil Resistant, Heat Resistant

Energy Saving : Energy Saving

Convey Speed : 1.25~2m/S

Convey Capacity : 507-811t/h

Specification : 1000mm width

HS Code : 8428330000

Contact Now

DT1000 Coal Industry Belt Conveyor

Technical Parameters

Model: DT1000

Max convey length: 10/5.5

Power: 10-20/7.5-11kw

Belt length power: 20-40/11-12kw

Convey speed:1.25-2m/s

Convey capacity: 507-811t/h

Technical parameters of DT Serial

Belt width (mm)	Convey length (m)	Power (KW)	Belt Length Power (KW)	Convey speed (m/s)	Convey capacity (T/H)
400	≤12/1.5	12~20/2.2~4	20~25/3.5~7.5	1.25~2.0	50~100
500	≤12/3	12~20/4~4.5	20~30/5.5~7.5	1.25~2.0	108~174
650	≤12/5	12~20/5.5	20~30/7.5~11	1.25~2.0	198~318
800	≤6/4	6~15/5.5	15~30/7.5~15	1.25~2.0	310~490
1000	≤10/5.5	10~20/7.5~11	20~40/11~12	1.25~2.0	507~811
1200	≤10/7.5	10~20/11	20~40/15~30	1.25~2.0	742~1188
1400	≤10/7.5	7.5~45	11~90	1.25~2.0	785~1560
1600	<10/11	11~132	15~280	1.25~2.0	1000~1800
1800	<10/11	11~132	15~280	1.25~2.0	1000~2200

The classification of DTII series belt conveyor

Categorized by installation:
1,fixed series
2,Mobile series
It is equipped with tire running mechanism and inclination adjusting device, it can be adjusted freely according to load and unload requirements.
